Nottepox P345

Description

NOTTEPOX P345 is a two-component, gun-applied, cake-like, polyester-based anchorage and assembly resin.

It is easy to apply with its special gun.
It sets fast.
It does not sag.
It can be applied to slightly damp surfaces.
It provides high resistance to chemicals such as sea water, jet fuel, oil, and medium resistance to soda and diluted acid solutions.
It can be used in hollow elements.

Holes of the correct diameter and depth are drilled using a drill.
The inside of the holes is thoroughly cleaned using a brush and compressed air to remove any debris.
The cartridge containing the anchor material is loaded into an application gun.
The pressing action is initiated, but the first mixture from the cartridge is not used until a homogeneous color is obtained.
The tip of the stirrer is inserted deep into the hole, and approximately half of the hole is filled with the material.
The anchor material is carefully inserted into the hole by slowly and slightly turning it.
The gun is retracted to fill the remaining part of the hole.
Any excess material overflowing from the hole should be removed before it hardens.
It is important not to disturb the fastener until the specified loading time has elapsed, and the material should be allowed to fully cure.

veriable

Packaging: 345 ml cartridge.
Storage Conditions: In its original packaging, when stored in ventilated, dry, and protected environments at +5°C to +25°C, protected from sun, rain and frost, its shelf life is 1 year from the date of manufacture.

Gloves, protective clothing, masks/goggles should be used during mixing and application, and contact of the product with eyes, mouth, and skin should be prevented.
In case of contact with skin, it should be washed with plenty of water, and in case of contact with eyes and swallowing, a doctor should be consulted.

Tensile Load on Concrete

Crude Metal Diameter (mm)	Hole Diameter (mm)	Hole Depth (mm)	Tensile Load (mm)
10	10	80	7
8	12	100	12
12	14	120	16
